Work Transport
Embracing local needs
Home
Products
Work Transport
Dimensions
Length (mm)
10740
Width(mm)
2550
Height (mm)
3400
Wheelbase (mm)
5420
Gross Vehicle Weight (kg)
15000
Curb Weight (kg)
10500
Seats
43+1+1
Engine
Power
270 HP, 6 cylinder
Displacement (L)
6.7
Maximum Torque (Nm)
970 @1400rpm
Transmission
Transmission
AMT with retarder
Chassis
Suspension
Leaf spring suspension
Braking system
Dual-circuit service fully dry braking system WABCO ABS
Steering
Power steering
Fuel tank (L)
350
A/C
30,000kcal/h
Battery (V)
24
Doors
Front single
Audio & video system
AM/FM radio LCD with USB player
General
Dimension (LxWxH) (mm)
10740 × 2550 × 3400
Gross Weight (kgs)
15000
Speed(km/h)
100
Turning radius
<20
Wheel base
5420
Seats
43+1+1
No. of doors
1
Audio & video system
FM/USB player
Engine, Driveline and Chassis
Engine
270 HP, 6 cylinder, 6.7L, 970@1400 rpm
Gear Box
AMT with retarder
Suspension system
Leaf spring
Brake system
Front disc and rear drum brakes, With ABS
Steering System
Power steering gear
Air conditioner (A/C)
Roof mounted, brushless fan, Dependent, with 30,000 Kcal/hr
Fuel tank
350 liters with anti-siphon fuel filling system
Electrical System
CAN System with OBD II diagnostic
Safety
Engine Compartment
Automatic Fire Suppression System
Smog Detection system
Battery Compartment
Smog Detection system
Wheels
Wheel Temperature label
Wheel Nut Lug
Tire Pressure monitoring system (TPMS)
Wheels
Neutral when bus stops
CCTV
Emergency escape roof hatch and door
Options
Others
Three Beacon lamp on the roof top
micro switch for opening doors (hidden)
