School Bus
Distinctively fun
Home
Products
School Bus
Dimensions
Length (mm)
8995
Width(mm)
2450
Height (mm)
3365
Wheelbase (mm)
4340
Gross Vehicle Weight (kg)
11920
Curb Weight (kg)
8720
Seats
35+1+1
Engine
Power
230 HP, 6 cylinder
Displacement (L)
6.7
Torque (Nm)
900 @ 1400rpm
Transmission
Transmission
Automatic
Chassis
Fuel tank (L)
220
Suspension
Leaf Spring Suspension
Front axle
Front Rigid
Rear Axle
Rear Hypoid
Braking system
Front disc and rear drum brakes, With ABS
Steering
Power steering
Body Structure
Monocoque body structure
A/C
26,000 Kcal/hr
Battery (V)
24
Doors
2
General
Dimension (LxWxH) (mm)
8995 × 2450 × 3365
Gross Weight (kgs)
11920
Speed(km/h)
80
Turning radius(m)
17
Wheel base(mm)
4340
Seats
35 + 1 + 1
No. of doors
1
Audio & video system
FM, LCD with USB player
Technical
Engine
230 HP, 6 cylinder, 6.7 L, Max torque 900Nm @ rpm1400
Transmission
Automatic transmission
Axle
Front Rigid and Rear Hypoid
Suspension system
Leaf Spring Suspension
Brake system
Front disc and rear drum brakes, With ABS
Steering System
Power steering
Air conditioner (A/C)
Roof mounted, brushless fan, Dependent, with 26,000 Kcal/hr
Fuel tank
220 liters with anti-siphon fuel filling system
Electrical System
CAN System with OBD II diagnostic
Safety
Engine Compartment
Automatic Fire Suppression System
Smog Detection system
Battery Compartment
Smog Detection system
Wheels
Wheel Temperature label
Wheel Nut Lug
Tire Pressure monitoring system (TPMS)
Others
Neutral when bus stops
CCTV
Emergency escape roof hatch and door
Stop board when the door opens
Optional
Vehicle tracking
Telematics
Information system
Destination board
Others
Micro switch for opening door
